3 Electrical Installation
YASKAWA Europe TOMP_C710606_75A V1000 IP66 - Quick Start Guide EN 13
Wiring Specification
Main Circuit
Use the fuses and wire sizes listed up in the table below when wiring the main circuit. Make sure not to exceed the given tightening torque values.
NOTICE: Equipment Hazard. Be sure to connect the recommended fuses between each input terminal and the main circuit power supply (3-phase: L1, L2, L3, single-phase:
L1, L2). As the V1000 Series IP66 Type enclosure is very compact, fuses are required to prevent serious damage to the drive components as well as prevent
personal injury in the event that a short-circuit occurs.
Tightening Torque Values
Tighten the main circuit terminals using the torque values provided by the table below.
Control Circuit
The control terminal board is equipped with screwless terminals. Always use wires within the specification listed below. For safe wiring it is
recommended to use solid wires or flexible wires with ferrules. The stripping length respectively ferrule length should be 8 mm.
Model
CIMR-VC
<1> The leakage current of this drive exceeds 3.5 mA. Therefore according to IEC61800-5-1 a protective earthing conductor with a cross section of at least 10 mm
2
(CU) of 16 mm
2
(Al) must
be used. Smaller protective earthing conductors can be used if automatic power supply interruption in case of discontinuity of the protective earthing conductor is provided.
<2> Use a ring terminal end to connect the ground wire to the ground terminal.
Main
Fuse
[Ferraz]
Applicable Wire
Gauge (mm
2
)
Recommended Wire Gauge (mm
2
) Terminal Size
L1,L2,L3,
U/T1,V/T2,W/T3,
-,+1,+2,B1,B2
L1,L2,L3,
U/T1,V/T2,W/T3,
-,+1,+2,B1,B2
<2>
U/T1,V/T2,W/T3,
-,+1,+2,B1,B2
<2>
Input <1> Output
BA0001 TRS5R 0.75 to 2.5 2.5 10 2.5 M3.5 M5
BA0002 TRS10R 0.75 to 2.5 2.5 10 2.5 M3.5 M5
BA0003 TRS20R 0.75 to 2.5 2.5 10 2.5 M3.5 M5
BA0006 TRS35R 2.5 to 6 2.5 10 2.5 M4 M5
BA0010 TRS50R 2.5 to 6 4 10 4 M4 M5
BA0012 TRS60R 2.5 to 6 6 10 6 M4 M5
4A0001 TRS2.5R 2.5 to 6 2.5 10 2.5 M4 M5
4A0002 TRS5R 2.5 to 6 2.5 10 2.5 M4 M5
4A0004 TRS10R 2.5 to 6 2.5 10 2.5 M4 M5
4A0005 TRS20R 2.5 to 6 2.5 10 2.5 M4 M5
4A0007 TRS20R 2.5 to 6 2.5 10 2.5 M4 M5
4A0009 TRS20R 2.5 to 6 2.5 10 4 M4 M5
4A0011 TRS30R 2.5 to 6 2.5 10 4 M4 M5
4A0018 A6T50 2.5 to 6 6 10 6 M4 M5
4A0023 A6T60 2.5 to 6 6 10 6 M4 M5
4A0031 A6T70 2.5 to 6 6 10 10 M5 M5
4A0038 A6T80 2.5 to 6 6 10 10 M5 M5
Terminal Size M3.5 M4 M5
Tightening Torque (Nm) 0.8 to 1.0 1.2 to 1.5 2 to 2.5
Wire Type Wire size (mm
2
)
Solid 0.2 to 1.5
Flexible 0.2 to 1.0
Flexible with ferrule 0.25 to 0.5
TOMP_C710606_75A_0_0_prePrint.pdf 45 21.12.2010 13:52:23
