12 Drive Control, Duty Modes, and Programming
YASKAWA ELECTRIC TOEP C710617 17D YASKAWA AC Drive GA700 Initial Steps EN 27
No.
(Hex.)
Name Description
b1-02
(0181)
Run Command Selection
1
Sets the input method for the Run command.
0: Keypad, 1: Analog Input, 2: Memobus/Modbus Communications, 3: Option PCB
b1-03
(0182)
Stopping Method
Selection
Sets the method to stop the motor after removing a Run command or entering a Stop
command.
0: Ramp to Stop, 1: Coast to Stop, 2: DC Injection Braking to Stop,
3: Coast to Stop with Timer, 9: Stop with Constant Distance
b1-04
(0183)
Reverse Operation
Selection
Enables and disables reverse operation. Disable reverse operation in fan or pump
applications where reverse rotation is dangerous.
0: Reverse Enabled, 1: Reverse Disabled
C1-01
(0200)
RUN
Acceleration Time 1 Sets the length of time to accelerate from zero to maximum output frequency.
C1-02
(0201)
RUN
Deceleration Time 1 Sets the length of time to decelerate from maximum output frequency to zero.
C2-01
(020B)
S-Curve Time @ Start of
Accel
Sets the time to start S-curve acceleration.
C2-02
(020C)
S-Curve Time @ End of
Accel
Sets the time to complete S-curve acceleration.
C2-03
(020D)
S-Curve Time @ Start of
Decel
Sets the time to start S-curve deceleration.
C2-04
(020E)
S-Curve Time @ End of
Decel
Sets the time to complete S-curve deceleration.
C6-01
(0223)
Normal / Heavy Duty
Selection
Sets the duty rating of the drive.
0: Heavy Duty Rating, 1: Normal Duty Rating
C6-02
(0224)
Carrier Frequency
Selection
Sets the carrier frequency for the transistors in the drive.
1: 2.0 kHz, 2: 5.0 kHz (4.0 kHz for AOLV/PM), 3: 8.0 kHz (6.0 kHz for AOLV/PM),
4: 10.0 kHz (8.0 kHz for AOLV/PM), 5: 12.5 kHz (10.0 kHz for AOLV/PM),
6: 15.0 kHz (12.0 kHz AOLV/PM), 7: Swing PWM 1 (Audible Sound 1),
8: Swing PWM 2 (Audible Sound 2), 9: Swing PWM 3 (Audible Sound 3),
A: Swing PWM 4 (Audible Sound 4), F: User Defined (C6-03 to C6-05)
d1-01 to d1-16
(0280 - 0291)
RUN
Reference 1 to 16 Sets the frequency reference in the units from o1-03 [Frequency Display Unit Selection].
d1-17
(0292)
RUN
Jog Reference Sets the Jog frequency reference in the units from o1-03 [Frequency Display Unit
Selection]. Set H1-xx = 6 [MFDI Function Select = Jog Reference Selection] to use the Jog
frequency reference.
d2-01
(0289)
Frequency Reference
Upper Limit
Sets maximum limit for all frequency references. This value is a percentage of E1-04
[Maximum Output Frequency].
d2-02
(028A)
Frequency Reference
Lower Limit
Sets minimum limit for all frequency references. This value is a percentage of E1-04
[Maximum Output Frequency].
E1-01
(0300)
Input AC Supply Voltage Sets the drive input voltage. Set this parameter to the nominal voltage of the AC power
supply.
E1-04
(0303)
Maximum Output
Frequency
Sets the maximum output frequency for the V/f pattern.
E1-05
(0304)
Maximum Output Voltage Sets the maximum voltage for the V/f pattern.
E1-06
(0305)
Base Frequency Sets the base frequency for the V/f pattern.
E1-09
(0308)
Minimum Output
Frequency
Sets the minimum output frequency for the V/f pattern.
E2-01
(030E)
Motor Rated Current
(FLA)
Sets the motor rated current in amperes.
EN
