Yazaki AROACE User Manual

3
STANDARD SPECIFICATIONS
Specifications
English (Metric)
WFC-SC5
Cooling Capacity
Mbtu/hr (kW/hr)
60.0 (17.6)
Chilled Water
Temperature
Inlet
°F (°C)
54.5 (12.5)
Outlet
°F (°C)
44.6 (7)
Evaporator Pressure Loss
PSI (kPa)
7.6 (52.6)
Maximum Operating Pressure
PSI (kPa)
85.3 (588)
Flow Rate
GPM (l/s)
12.1 (0.76)
Water Retention Volume
Gal (liters)
2.1 (8)
Cooling Water
Heat Rejection
Mbtu/hr (kW/hr)
145.7 (42.7)
Temperature
Inlet
°F (°C)
87.8 (31)
Outlet
°F (°C)
95 (35)
Cond/Abs Pressure Loss
PSI (kPa)
5.6 (38.6)
Maximum Operating Pressure
PSI (kPa)
85.3 (588)
Flow Rate
GPM (l/s)
40.4 (2.55)
Water Retention Volume
Gal (liters)
9.8 (37)
Heat Medium
Heat Input
Mbtu/hr (kW/hr)
85.7 (25.1)
Temperature
Inlet
°F (°C)
190.4 (88)
Outlet
°F (°C)
181.4 (83)
Range
°F (°C)
158-203 (70-95)
Generator Pressure Loss
PSI (kPa)
11.2 (77.0)
Maximum Operating Pressure
PSI (kPa)
85.3 (588)
Flow Rate
GPM (l/s)
19.0 (1.2)
Water Retention Volume
Gal (liters)
2.6 (10)
Electrical
Voltage
Volts
115/208/230
Frequency
Hz
60
Phase
Phase
1
MCA
Amps
0.89
MOCP
Amps
15
Consumption
Watts
48
Capacity Control
On - Off
Noise Level
dB(A)
38
Piping
Chilled Water
Inches
1-1/4 NPT
Cooling Water
Inches
1-1/2 NPT
Heat Medium
Inches
1-1/2 NPT
Dimensions
Width
Inches (mm)
23.4 (594)
Depth
Inches (mm)
29.3 (744)
Height
Inches (mm)
71.5 (1815)
Height with Lifting Lugs Removed
Inches (mm)
69.1 (1755)
Weight
Dry
lbs (kg)
805 (365)
Operating
lbs (kg)
926 (420)
Table 1 - Specifications

Yazaki AROACE Specifications

General

Brand	Yazaki
Model	AROACE
Category	Chiller
Language	English
