WFC-SC5 Wiring Diagram Legend, Rev 1B
Auxiliary Contact Set #1 - Not Used
Auxiliary Contact Set #2 - Not Used
Operation indicator. Closes/Illuminates when chiller is Enabled.
Error indicator. Closes/Illuminates when error condition exists.
Cooling Interlock Switch. Cooling tower sump level switch or cooling water flow switch.
Cooling Water Inlet Temperature
Cooling Tower Fan Operation Indicator. Closes when fan is on.
Chilled Water Flow Switch
Fuse. Fuji model FGAO-2 (2A)
Fuse. Fuji model FGAO-2 (4A)
Freeze Protection Enable/Disable. If open, Freeze Protection Logic will not be used.
Output contact tied to AUX1. Closes when AUX1 is closed - Not Used
Output contact tied to AUX2. Closes when AUX2 is closed - Not Used
Chilled Water Pump ON signal. Supplied by the chiller.
Chilled Water Pump Operation Input. Pump overloads.
Cooling Water Pump ON signal. Supplied by the chiller.
Cooling Water Pump Operation Input. Pump overloads.
Heat Medium Pump ON signal. Supplied by the chiller.
Heat Medium Pump Operation Input. Pump overloads.
Power Light. Illuminates when power is on.
Refrigerant Blow-down Valve
Chilled Water Outlet Temperature
Power Surge Protection Module
Table 2 – Internal Wiring Diagram Legend
INSTALLATION
RECEIVING
When the absorption chiller is
delivered, inspect it for transit damage.
Should any damage have occurred, do
not proceed with installation until the
Yazaki distributor has been notified and
any required remedial actions have been
completed.
Remember to properly plan the route
to the installation site. Also, keep in mind
when choosing the site, the unit will
someday have to be replaced, so be
mindful of permanent and semi-
permanent barriers.
