WFC- SC(H) Series .Installation

- 13 -

5-3. Junction box electrical wiring

5.3.1 Location of Junction box

Junction box is located left bottom of the Chiller (refer to figure 5-3-1a.)

<WFC-SC (H) 10, 20, 30 >

<WFC-SC50>

Junction box is located rear bottom of the Chiller (refer to figure 5-3-1b.)

Figure 5-3-1b (SC50)

Junction box

Figure 5-3-1a (SC (H) 10, 20 and 30)
