WFC- SC(H) Series .Installation
- 9 -
4.2 Chilled-Hot Water Piping
Water supply and accommodation of expansion of the chilled water circuit is afforded
by either an open cistern or closed expansion tank with check/pressure reducing
valves as shown in figure 11.
Plan piping with a rising grade of 1/200. And where high points exist in the piping
circuit, install purge valves to expel trapped air.
Valve & Thermometer Wells
Ch il le r
H e a ter
Ch il l er-
H e a ter
C h ille d -h o t
w a t e r p u m p
Fan c o il
Fan c o il
E xp a n s io n
ta n k
Closed System
Open Sys tem
W a ter s u p p ly
C i ste r n
10 0 0 m m M inim u m
W a ter s u p p ly
C h ec k/ r e duc i n g
v a lv e
Re lie f
va lv e
C h ille d -h o t
w a t e r p u m p
Chiller-
Heater
Chilled-hot water pump
Drain valve
Stop
valve
Balance
valve
Thermometer
wells
Manual vent valve
Caution.
Do not exceed
588.4kPa in the
chilled-hot
water circuit
Caution.
Do not install any valves in the expansion pipeline
Figure 11
Figure 12
