Yealink Camera-Hub User Manual

Do not connect the switch to the Internet,
otherwise it will cause network abnormalities.
The system should be used with Yealink
original power adapter (48V/0.7A) only. The
use of the third-party power adapter may
damage the system. The cable should be
replaced at once if its skin is broken.
The switch and Ethernet cables should be
purchased separately.
Connections
...
Microphone
UVC80
UVC80
Switch
Power Adapter
Mspeaker(Optional)
VCM34(Optional)
HDMI HDMI
Mini-PC
Ethernet Cable
CAT5e
3m RCA to
3.5mm Audio Cable
UBS3.0 to Ethernet
Adapter
Camera-Hub
CAT5e
CAT5e
CAT5e
CAT5e
CAT5e
CAT5e
VCM34(Optional)
VCM34(Optional) VCM34(Optional)
3
