Yealink MVC640 User Manual

5
1. Press the power button on the bottom left of MCore Pro, and the Microsoft Windows 10 IoT
Enterprise Edition operating system will be automatically loaded after starting MCore Pro.
Note: When starting up the system for the rst time, you need to connect a mouse to complete the
initial conguration. We recommend using the wireless mouse and keyboard kit.
After the system is initialized, you can use MTouch E2 to complete the system login and settings,
and the device will automatically start the Microsoft Teams conference system application and
enter the setting page.
2. Select the check box on the EULA page, and then tap Next.
3. Enter the account, the password on the Account page, and then tap Next. Supports Microsoft
Teams Rooms or Skype® for Business accounts.
4. On the Advanced page, congure the domain and tap Next.
5. Tap Finish to complete the setup wizard.
1. Connect the WPP30 to the USB port of the MTouch E2.
When pairing, the LED indicator of WPP30 is orange. And the
pairing is successful, the LED indicator turns green breathing light.
2. Connect the paired WPP30 to the USB-A/USB-C port on your PC.
3. On the WPP30, press the presentation button to share full screen.
1. Tap More > to enter the Camera Control page.
5
Initial Setup
6
Features
Wireless Sharing
Control UVC84 Camera Position
1$
WPP30

Yealink MVC640 Specifications

General

Bluetooth	Yes
Pan range	-100 - 100 °
Product type	Group video conferencing system
Product color	Black, Grey
Tilt angle range	-45 - 90 °
Number of persons	- person(s)
Signal-to-Noise Ratio (SNR)	63 dB
Processor family	Intel® Core™ i5
Computer system type	Mini PC
Operating system installed	Windows 10 IoT Enterprise
Internal memory	8000 MB
Storage media type	SSD
Total storage capacity	128 GB
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB connector type	USB Type-A, USB Type-B
Ethernet LAN (RJ-45) ports	1
HDMI output ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Telepresence	-
Display diagonal	8 \
Touchscreen type	Capacitive
Display resolution	1280 x 800 pixels
Megapixel	- MP
Camera type	Single camera
Digital zoom	3 x
Optical zoom	12 x
Focus adjustment	Auto
Image sensor size	- \
Focal length range	3.9 - 46.8 mm
Aperture range (F-F)	1.6 - 2.8
Camera shutter speed	1/60 - 1/10000 s
Minimum illumination	0.1 lx
Diagonal field of view	80 °
Vertical field of view	45 °
Horizontal field of view	73 °
Maximum frame rate	30 fps
Speaker power	10 W
Frequency range	100 - 20000 Hz
Microphone pick-up range	6 m
Output voltage Total Harmonic Distortion (THD)	1 %
Number of microphone arrays	3
Current	0.7 A
AC input voltage	100-240 V
DC input voltage	48 V
Power source type	AC
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	7600 g
