Yealink IP Phone – SIP-T19 E2 & SIP-T19P E2
Note:
• The hook switch tab has a lip which allows the handset to stay on-hook when the IP phone is mounted
b) Detach the stand:
2. Connect the handset and optional headset, as shown below:
Note:
• The headset should be purchased separately.
3. Connect the network and power, as shown below:
You have two options for network and power connections. Your system administrator will advise you which
one to use.
Note:
• The IP phone should be used with Yealink original power adapter (5V/600mA) only. The use of the
third-party power adapter may cause the damage to the phone. If you are connecting a PC to your
phone, we recommend that you use the Ethernet cable provided by Yealink.
If inline power (PoE) is provided, you don’t need to connect the power adapter.
Make sure the hub/switch is PoE-compliant. PoE is only applicable to the SIP-T19P E2 IP phone.
