User Guide for the SIP-T21(P) E2 IP Phone
122
The valid multicast IP addresses range from 224.0.0.0 to 239.255.255.255.
7. Press the Save soft key to accept the change or the Back soft key to cancel.
Multicast paging key is configurable via web user interface at the path DSSKey->Line
Key.
To configure a paging list key via phone user interface:
1. Press Menu->Features->DSS Keys.
2. Select the desired DSS key.
3. Press or , or the Switch soft key to select Key Event from the Type field.
4. Press or , or the Switch soft key to select Paging List from the Key Type
field.
5. (Optional.) Enter the string that will appear on the LCD screen in the Label field.
6. Press the Save soft key to accept the change or the Back soft key to cancel.
Paging list key is configurable via web user interface at the path DSSKey->Line Key.
To configure paging list via phone user interface:
1. Press the paging list key when the phone is idle.
2. Press or to select a desired paging group.
The default tag is Empty if it is not configured before.
3. Press the Option soft key and then press the Edit soft key.
4. Enter the multicast IP address and port number (e.g., 224.5.6.20:10008) in the
Address field.
