Yealink SIP-T22P Quick Start Guide

3. Connect the network and power, as shown below:
You have two options for network and power connections. Your system administrator will advise you on which one
to use.
After the IP phone is connected to the
network and supplied with power, it automatically
begins the initialization process. After startup,
the phone is ready for use. You can configure the
phone via web user interface or phone user interface.
Initializing
Please wait ...
PC Connection
(Optional)
Power Adapter
(DC 5V)
A
AC Power Option
B
PoE ( Power over
Ethernet ) Option
PC Connection
(Optional)
IEEE 802.3af compliant
PoE Hub/Switch
2
Note: PoE is only applicable to the SIP-T22P IP phone. If inline power (PoE) is provided, you do not need to
connect the power adapter. Make sure the hub/switch is PoE-compliant.
Startup

Yealink SIP-T22P Specifications

General

DC-in jack	Yes
Expansion module support	No
Ethernet LAN (RJ-45) ports	2
Volume control	Digital
Keypad number of keys	32
Number of handles included	1 pc(s)
Power requirements	100 - 240 VAC, 5 VDC
Power consumption (typical)	2.6 W
Power consumption (PowerSave)	1.5 W
Voice codecs	G.722, G.723, G.726
Touchscreen	-
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	300 entries
Number of VoIP accounts	3
Security algorithms	HTTPS, SRTP
Flash memory	8 MB
Internal memory	32 MB
Password protection type	User
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black

Weight and Dimensions

Depth	200 mm
Width	185 mm
Height	90 mm
Weight	770 g
