Yealink SIP-T27G Auto Provisioning Guide

Yealink IP Phones Auto Provisioning Guide
20
Product Name
Common CFG File
SIP-T40G
y000000000076.cfg
SIP-T29G
y000000000046.cfg
SIP-T27G
y000000000069.cfg
SIP-T23P/G
y000000000044.cfg
SIP-T21(P) E2
y000000000052.cfg
SIP-T19(P) E2
y000000000053.cfg
CP860
y000000000037.cfg
CP920
y000000000078.cfg
W53P/W60P/CP930W-Base
y000000000077.cfg
W52P/W56P
y000000000025.cfg
Common CFG file contains configuration parameters which apply to phones with the same
model, such as language and volume.
The following figure shows a portion of the common CFG file:
The following table lists guidelines you need to know when editing the common CFG file:
Item
Guidelines
#
The line beginning with “#” is considered to be a comment.
#!version:1.0.0.1
It must be placed in the first line.
Do not edit and delete.
Filename
The filename complies with the requirements that are listed in the
above table.
Line formats and
Rules
Each line must use the following format and adhere to the following
rules:

Yealink SIP-T27G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Gold
Wall mountable	Yes
Display diagonal	3.66 \
Display resolution	240 x 120 pixels
RJ-9 ports quantity	2
USB 2.0 ports quantity	1
Voice codecs	CNG, G.711, G.722, G.723.1, G.726, G.729, G.729ab, VAD, iLBC
Dual-Tone Multi-Frequency (DTMF) modes	SIP info
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Bluetooth	-
Security algorithms	AES, MD5
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Volume control	Digital
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	210 mm
Width	265 mm
Height	170.5 mm
