Yealink SIP-T42S Quick Start Guide

4
Quick Start Guide
Ultra-elegant Gigabit IP Phone – SIP-T42S
2. Connect the handset and optional headset, as shown below:
Note:
• The headset or wireless headset adapter EHS36 should be purchased separately.
• The EXT port can also be used to connect the expansion module EXP20. For more information on how to
use the EHS36 and EXP20, refer to Yealink EHS36 User Guide and Yealink EXP20 User Guide.
3. Connect the USB flash drive, as shown below:
Note:
• The USB port can also be used to connect Bluetooth USB dongle BT40 or Wi-Fi USB dongle WF40. The
Bluetooth USB dongle BT40 or Wi-Fi USB dongle WF40 should be purchased separately. For more
information on how to use the BT40 and WF40, refer to Yealink Bluetooth USB Dongle BT40 User Guide
and Yealink Wi-Fi USB Dongle WF40 User Guide.

Yealink SIP-T42S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Lines quantity	12 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	6
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
