6
Quick Start Guide
Ultra-elegant Gigabit IP Phone – SIP-T42S
STARTUP
After the IP phone is connected to the network and supplied
with power, it automatically begins the initialization process.
After startup, the phone is ready for use. You can configure the
phone via web user interface or phone user interface.
CONFIGURING YOUR PHONE
CONFIGURING VIA WEB USER INTERFACE
Accessing the web user interface:
1. Press the OK key when the phone is idle to obtain the IP address of the phone.
2. Open a web browser on your computer, enter the IP address into the address bar
(e.g., "http://192.168.0.10" or "192.168.0.10"), and then press the Enter.
3. Enter the user name (default: admin) and password (default: admin) in the login page and click Confirm.
Network Settings: Click on Network->Basic->IPv4 Config
You can configure the network settings in the following ways:
DHCP: By default, the phone attempts to contact a DHCP server in your network to obtain its valid
network settings, e.g., IP address, subnet mask, gateway address and DNS address.
Static IP Address: If the phone cannot contact a DHCP server for any reason, you need to configure the
IP address, subnet mask, gateway address, primary DNS address and secondary DNS address for the phone
manually.
Note:
The IP phone also supports IPv6, but IPv6 is disabled by default.
The wrong network settings may result in inaccessibility of the phone and may have an impact on
the network performance. Contact your system administrator for more information.
Account Settings: Click on Account->Register->Account X (X= 1,2,3...11,12)
Parameters of the account:
Register Status: It shows the register status of the current account.
Line Active: You can select Enabled/Disabled to enable/disable the account.
Label: It is shown on the LCD screen to identify the account.
Display Name: It is shown as Caller ID when placing a call.
Register Name: It is an authenticated ID for authentication provided by ITSP (required).
User Name: It is provided by ITSP for registration (required).
Password: It is provided by ITSP for registration (required).
Server Host: It is provided by ITSP for registration (required).

Other manuals for Yealink SIP-T42S

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yealink SIP-T42S and is the answer not in the manual?

Yealink SIP-T42S Specifications

General IconGeneral
ManualYes
Cables includedLAN (RJ-45)
Number of handles included1 pc(s)
Lines quantity12 lines
Phonebook capacity1000 entries
Number of VoIP accounts12
MountingDesk/Wall
Handset typeWired handset
Product typeIP Phone
Product colorBlack
Voice codecsCNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Operating temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)10 - 95 %
Display diagonal2.7 \
Display resolution192 x 64 pixels
AC adapter input voltage100 - 240 V
AC adapter output current1.2 A
AC adapter output voltage5 V
Dual-Tone Multi-Frequency (DTMF) modesIn-band, Out-of band, SIP info
Volume controlDigital
Number of programmable keys6
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports2
Networking standardsIEEE 802.3af
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Supported network protocolsSIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Weight and Dimensions IconWeight and Dimensions
Depth189 mm
Width212 mm
Height175 mm
Package depth223 mm
Package width246 mm
Package height120 mm
