Yealink SIP-T46G Quick Start Guide

3. Connect the network and power, as shown below:
You have two options for network and power connections. Your system administrator will advise you which one to
use.
A
AC Power Option
PC Connection
(Optional)
Power Adapter
(DC 5V)
B
PoE ( Power over
Ethernet ) Option
PC Connection
(Optional)
IEEE 802.3af compliant
PoE Hub/Switch
Welcome
Initializing... Please wait
2
Note: The IP phone should be used with Yealink original power adapter (5V/2A) only. The use of the third-party power
adapter may cause the damage to the phone.
Startup
PoE-compliant.
After the IP phone is connected to the network and supplied
with power, it automatically begins the initialization process.
After startup, the sign-in screen appears on the phone LCD
screen. Refer to Sign-in on page 3 to sign into to the Skype for
Business Server.
If inline power (PoE) is provided, you don’t need to connect the power adapter. Make sure the hub/switch is

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
