Yealink SIP-T46S Quick Installation Guide

2. Insert the tabs on the wall mount bracket into the
slots on the back of IP phone. And then slide the wall
mount bracket to right.
For a SIP-T48S/T48G/T29G/T27P/T27G IP phone:
PUSH
For SIP-T46S/T46G IP phones:
Yealink provides the wall mount drilling template for
each IP phone model, which locates and marks the
position for mounting the screws (not provided) on the
wall, as shown below:
Mounting the Wall Mount Bracket
For a SIP-T58V/T58A/T56A IP phone:
PUSH
ＰＣ
Ｉｎｔｅｒｎｅｔ
ＤＣ５Ｖ
ＰＣ
Ｉｎｔｅｒｎｅｔ
ＤＣ５Ｖ
For a SIP-T58V/T58A/T56A IP phone:
www.yealink.com
Wall Mount Quick Installation Guide
For a SIP-T48S/T48G IP phone:
118.00mm
118.00mm
Screw position
Max:8mm
(0.315”)
Min:6.5mm
(0.256”)
x 4
Max:4.5mm
(0.177”)
Max:8mm
(0.315”)
Min:6.5mm
(0.256”)
Screw position
x 3
147.90mm
81.76mm
70.11mm

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
