Yealink T56A User Manual

2
Version 1 / 09.2018 (en)
2. Used symbols
Type Icon Description
Notice
Important information and notices that you
have to pay attention to.
Hint
Useful hints that provide additional
information.
Action – is marked with a dash
Result of an
action
⇒ is marked with an arrow
List • is marked with a bullet point
B. Security
1. Notes
The device was produced in accordance with the most common security standards. Nevertheless,
note the safety guidelines in order to use the device securely. Please note the following safety
guidelines to lower risk of burning, electric shocks, and similar risks.
General guidelines
Keep the device dry and clean at transport, storage, and usage.1.
Avoid collisions and drops of the device at transport, storage, and usage.2.
Do not open the device case and do not try to repair the device on your own.3.
Guidelines for usage and operation
Check whether the power supply voltage is in accordance with the device's voltage.1.
Pay attention to dry hands before using a cable.2.
Do not spill liquids on the device.3.
Guidelines for cleaning
Disconnect and unplug the device from the power supply before cleaning.1.
Use a soft, dry, antistatic cloth to clean the device.2.

Yealink T56A Specifications

General

Operating System	Android 5.1.1
Display	7 inch capacitive touch screen
Resolution	800 x 480
USB Ports	2 x USB 2.0
Ethernet	2 x Gigabit Ethernet ports
PoE	Yes, IEEE 802.3af class 3
Audio	HD Voice
Expansion Module	Supports EXP50
Headset Support	Yes, RJ9, USB, Bluetooth
Local Phonebook	Up to 1000 entries
SIP Accounts	Up to 16
Supported Protocols	SIP
Power Supply	AC 100~240V input and DC 5V/2A output
Operating Temperature	0°C to 40°C
Humidity	10 to 95% relative humidity, noncondensing
Wi-Fi	Optional via WF40/WF50
