Yealink VC110 Quick Guide

Suggestedemailtoyournetworkadministrator:
Hello,

WerecentlypurchasednewYealinkvideoconferencinghardwareendpoint(s)fromEasymeetingand
wouldlikeyourhelpgettingthissetup.Inordertodoso,weneedyoutoreviewandmakethe
necessarychangesonournetwork/firewallandtherequestedinformationforeachsystem.Thiswill
needtobedoneforeachsystemthatwepurchased.

NetworkRecommendations
ForYealinkunits,Easymeetingrecommendsstatic1-to-1NATconfigurations.Youwillneedtocreatea
static1-to-1NATpolicyfromthepublicsideofyourfirewalltotheprivatesideoftheLAN.Note,some
firewallsrequireyoutocreateanadditionalpolicytotranslatetheprivateLANtothepublicsideofthe
firewall.Theyrecommendthatwerefertoourfirewalladministrationguideorourfirewall
manufacturerwithanyquestions.

TheyaskthatyouensureanyH.323protocolinspectionenginesaredisabled.Thisincludes,butisnot
limitedto,H.323,H.245,H.239andH.225inspection.Alsoensurethatwedon'thaveanypre-existing
rulesorservicesthatmayconflictwiththerecommendationsgiven.Theysuggestthatnew,
bi-directionalrulesfortheportslistedbelowarecreatedandclearlyindicatedforfuturereference.

ConfigurePortMapping
Youmustforwardthefollowingportstothepublicnetworkonthefirewall:
Function
Port
ProtocolType
H.323registrationport
1719
UDP
H.323callport
1720
TCP
Audio,Video,andDatamediastream
50000-50499
TCP/UDP
Webmanagement
(optionalbutrecommended)
443
TCP
SIP(optional)
5060-5061
TCP/UDP

Itisrecommendedthatyouforwardthewebmanagementport(443/TCP)tothepublicnetwork,so
thattheEasymeetingExpertscanremotelymanagethedeviceasaddedsupport/troubleshooting.We
HIGHLYrecommendthatyouchangethedefaultpasswordofthedevicefrom“0000”andprovidethe
EasymeetingServiceCenterwiththeupdatedinformation.

PleaseprovideuswiththefollowinginformationforeachYealink:
DedicatedpublicIP:
Subnetmask:
Gateway:
DNS:

Ifyouhaveanyquestionsorconcerns,youcanreachouttoEasymeetingSupportdirectlyat
support@easymeeting.netorbyphoneat855-299-3279ext1.
Thanks,
ContactUs
support@easymeeting.net
helpdesk.easymeeting.net


Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
