Yealink W78P User Manual

2
2a. (Desktop Installation) Attach and remove the base stand.
Attach the Base Stand
Remove the Base Stand
MAC
SN
MAC
SN
MAC
SN
Align the snap-ts with the corresponding
holes and push forward, snapping them
into the holes.
Remove the snap-ts from the
holes horizontally.
2b. (Wall-Mount Installation) Attach the base station.
Assembling the DECT Phone
1. Connect the base station power and the network using method a or
method b.
a. AC Power Option
b. PoE (Power over Ethernet) Option
IEEE 802.3af compliant
PoE Hub/Switch
Note:
• If you choose method a, use Yealink supplied power adapter (5V/0.6A). A third-party power adapter may
damage the base station.
• If you choose method b, you do not need to connect the power adapter. Make sure the hub/switch is PoE-
compliant.

Yealink W78P Specifications

General

Mounting	Desk/Wall
Handset type	Wireless handset
Product type	IP mobile phone
Product color	Black
Backlight keypad	Yes
Wi-Fi	-
Bluetooth version	5.1
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Number of melodies	9
Maximum indoor range	50 m
Maximum outdoor range	300 m
Power over Ethernet (PoE)	No
Ethernet LAN (RJ-45) ports	1
Lines quantity	- lines
Phonebook capacity	1000 entries
Standby time	166 h
Battery capacity	1460 mAh
AC adapter input voltage	100 - 240 V
Keypad number of keys	25
Number of function keys	6
Battery voltage	3.7 V
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Storage relative humidity (H-H)	-30 - 70 %
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Number of simultaneous touchpoints	20
Number of handles included	1 pc(s)
Certification	CE, FCC, RoHS, REACH, ISO 9001
Sustainability certificates	RoHS, Federal Communications Commission (FCC), CE, REACH

Weight and Dimensions

Weight	6836 g
Package weight	7546 g
Base dimensions	130 x 100 x 25.1 mm
Handset dimensions (WxDxH)	157 x 51 x 24 mm
