Yealink W78P - Handset Hardware Overview; Handset Component Identification

5
Hardware Component Instructions
4
7
8
11
4
5
6
9
10
12
13
14
2
3
1
Receiver
Power LED Indicator
Phone Screen
Soft Keys
Message Key
Navigation Keys
On-hook Key/Power Key
Keypad
Mute Key
Microphone
TRAN Key
Off-hook Key
OK Key
Speakerphone Key
Soft Keys
Note:
• If the handset is registered to the base station successfully, the handset LCD screen prompts
“Handset Subscribed” and “Base NO.”( the last 4 characters indicate the base station’s MAC
address).
• If the handset LCD screen prompts “Searching for Base”, check that your base station is
powered on.
