ARC | OWNER’S MANUAL
12
EXPLODED VIEW PARTS LIST
ITEM # PART # DESCRIPTION
TORQUE
(NM)
QTY
1 ARC FRAME ASSEMBLY 1
1.3 400100209 DOWN TUBE GUARD, ARC 1
1.4 400100210 CS/SS PROTCTOR, ARC 1
1.5 400100211 CS LOWER PROTECTOR, ARC 1
2 HARDTAIL ASSEMBLY PARTS
1
2.1 300030148 WASHER 5.1 X 8.9 X 1.0 MM 4
2.2 300030010 SHCS, M5 X 0.8, 16L 4
2.3 300060078 ASSEMBLY, YETI SEAT CLAMP, BOLT ON, 31.6 1
2.4 300060080 SRAM UNIVERSAL HANGER 1
2.6 300030173 SCREW, FH, M4 X 0.7, 10L 1
2.7 300040518 COVER-CABLE PORT, SINGLE, RIGHT EXIT 1
2.8 300040521 CLAMP, HT PORT SINGLE, PA6 1
2.9 300040523 COVER, HT PORT, BLIND, PA6 1
2.10 100425009 AXLE, M12X1 X 174L, BOLT-ON, BLACK 1
2.11 300040524 CABLE PORT COVER, HEAD TUBE, 2 PIECE 2
2.12 300040522 CLAMP, HT PORT DOUBLE, PA6 1
2.13 300030177 SCREW, FH, M4 X 0.7, 25L 2
2.14 300040519 CABLE PORT COVER, DOWN TUBE 1
2.15 300040514 CLAMP-LOWER PORT 1
2.16 300030174 SCREW, FH, M4 X 0.7, 15L 2
