Yeti ARC - Frame Standards and Specifications; Rear Travel; Wheel Size Compatibility; Bottom Bracket Standard

ARC | OWNER’S MANUAL
6
REAR TRAVEL
0MM
WHEEL SIZE
29”
FRAME SIZE
SM, MD, LG, XL
BOTTOM BRACKET
PF92
REAR WHEEL
148MM X 12MM (BOOST)
SEATPOST
31.6MM
CHAINLINE
55MM
HEADSET
INTEGRATED 41MM/52MM TAPERED
REAR BRAKE POST MOUNT
160MM
MIN/MAX CHAINRING
28T MIN/34T MAX
MIN MAX REAR ROTOR
160MM MIN/180MM MAX
AXLE SPEC
174MM M12X1
FRAME STANDARDS
