SB160 | OWNER’S MANUAL
18
EXPLODED VIEW PARTS LIST
ITEM # PART # DESCRIPTION
TORQUE
(NM)
QTY
1 SB160 FRONT TRIANGLE ASSEMBLY 1
1.1 SB160 FRONT TRIANGLE ASSEMBLY 1
2
SB160 SWINGARM ASSEMBLY
1
2.1 SB160 SWINGARM 1
3 SB160 SMALL PARTS ASSEMBLY
1
3.1 300030361 COLLET AXLE, 15MM X 58.5L, M15X1.5 25 1
3.2 300030362 COLLET NUT, M15, 9.5 THICK, ROUND CAP 4
3.3 300030364 SHOULDER SCREW, 15 X 27.35L, M15 THREAD, SS PIVOT 25 2
3.4 300030376 COLLET AXLE 15MM, 43.5L 25 1
3.5 300030365 RACE EXTENDER, 25 X 15.1 X 3.35 4
3.6 300030366 CLAMP BASE, 23MM X 3.5T, BRAKE HOUSING 1
3.7 300030367 COLLET NUT, M15 X 1.5, SHIFTER HOSE CLAMP 1
3.8 300030368 CLAMP CAP, HOUSING 2
3.9 300030378
COLLET WEDGE SUB-ASSEMBLY 15MM,
M4 THREADED WEDGE BOLT
14 2
3.10 300040486 COLLET WEDGE SUB-ASSEMBLY 10MM 8 1
3.11 300030057 SHCS, M6 X 1.0, 20L 12 4
3.12 300030214 WASHER 6.3 X10.0 X 1.0 MM 4
3.13 200020422 ASSY, SWITCH INFINITY, MECHANISM, FACTORY SERIES 1
3.14 300030296 COLLET AXLE M10X1.0, 30.5L X 10.5T 15 1
3.15 300030375 SHOCK EXTENDER BEARING EXTENSION 2
3.16 200020409 SB160 LINK ASSEMBLY 1
3.16.1 300040540 SB160 LINK 1
3.16. 2
HNA00000BA0
0000000000
BEARING, 3802-2RS, 15 X 24 X 7 4
3.16. 3 300030369 SPACER, 15.2 X 17 X 7.3L 1
3.17 300030372 BOLT, FEMALE, 8 X 41.0, M6 THREAD 1
3.18 300030371 BOLT, FEMALE, 8 X 45.0, M6 THREAD 1
3.19 300030370 SCREW, MALE, M6X12.0MM 10 2
3.20 300030062 WASHER 6.5 X 12.5 X 0.5 MM 2
3.21 300030069 WASHER 8.5 X 12.5 X 0.5 MM 2
3.22 200020323 ASSY, SHOCK EXTENDER_60MM, BOTTOM 1
3.22.1 300040503 SHOCK EXTENDER BOTTOM [60MM] 1
3.22.2 300020032 BEARING, 398 MAX DBL, 8 X 19 X 10/11 1
3.23 200020322 ASSY, SHOCK EXTENDER_60MM, TOP 1
3.23.1 300040502 SHOCK EXTENDER TOP [60MM] 1
3.23.2 300020032 BEARING, 398 MAX DBL, 8 X 19 X 10/11 1
3.24 300030374 SHOCK EYELET SPACER 1
3.25 300030174 SCREW, FH, M4 X 0.7, 16L 2.5 1
3.26 300030177 SCREW, FH, M4 X 0.7, 25L 2.5 3
3.27 300030357 SHCS, LOW PROFILE, M5 X 0.8, 16L 5 5
3.28 300030358 WASHER 5.2 X 8.8 X 1.0 MM, STAINLESS ED BLACK 2
3.29 300040518 COVER-CABLE PORT, SINGLE, RIGHT EXIT 3
3.30 300040522 CLAMP, HT PORT DOUBLE, PA6 1
3.31 300040521 CLAMP, HT PORT SINGLE, PA6 2
3.32 300040524 CABLE PORT COVER, HEAD TUBE, 2 PIECE 2
3.33 300030173 SCREW, FH, M4 X 0.7, 10L 2.5 3
3.34 300060080 SRAM UNIVERSAL HANGER 25 1
3.35 300060078 ASSY, YETI SEAT CLAMP, BOLT ON, 31.6 1
3.36 300040523 COVER, HT PORT, BLIND, PA6 1
3.37 200020418 DT GUARD, MY23 OUTER, PA/ABS 1
3.38 300040542 COVER-CABLE PORT, BLANK, RIGHT EXIT 1
3.39 300040510 FRAME PLUG, CABLE PORT 2
3.40 100425018 REAR AXLE M12X1 X 172L BOLT-ON BLACK UDH 15 1
4
SB160 SHOCK SUB ASSEMBLY
1
