15
IM AQ6370D-02EN
Connecting a USB Storage Device
Supported USB Storage Devices
The instrument supports USB memory (USB card adapters).
You cannot use a USB storage device not recognized by the instrument. If the USB
storage device’s drive is partitioned, only the primary partition (F:) is recognized. If there
are two or more USB storage devices, only the first connected device is recognized.
If you restart the instrument, it the USB storage devices that were connected will still be
recognized.
Connections
Connect the USB storage device to the USB connector on the front panel of the
instrument.
USB
POWER
Removing
See section 8.1 of the User’s Manual, IM AQ6370D-01EN. (Using the REMOVE USB
STORAGE soft key.)
CAUTION
Do not remove the USB storage device or turn the power OFF while the USB
storage device access indicator is blinking. This can damage the data on the device
or the device itself.
French
ATTENTION
Ne retirez pas le dispositif de stockage USB et ne coupez pas l’alimentation
lorsque le voyant d’accès au dispositif de stockage USB clignote. Cela risquerait
d’endommager le dispositif ou les données se trouvant sur ce dernier.
Connecting with Other Devices
You can use the GP-IB, RS-232C, or Ethernet interface to connect other external
instruments to the AQ. For details, see the Remote Control User’s Manual, IM AQ6370C-
17EN.
Note
When connecting a GP-IB instrument such as an external computer, or a CRT or other display
to the instrument, always turn OFF the power to the instrument and the instruments to be
connected first. Leaving the power ON while making connections can damage the equipment.
7 Connecting the Device
