YOKOGAWA AQ6370D Getting Started Guide

26
IM AQ6370D-02EN
11 Specifications
For the specifications of the limited model (SUFFIX --02, -01), see IM AQ6370D-51EN, a manual specifically for the limited model
(SUFFIX -02, -01).
Item Specifications
Applicable fiber SM (9.5/125 µm), MMF (50/125 µm, 62.5/125 µm), Large core size fibers (core diameter of
    upto200μm)
Measurement wavelength range
1
600 to 1700 nm
Wavelength accuracy
1, 2, 5
Wavelength range Standard (AQ6370D-10) High performance (AQ6370D-20)
1520 to 1580 nm ±0.02 nm ±0.01 nm
1450 to 1520 nm ±0.04 nm ±0.04 nm
1580 to 1620 nm ±0.02 nm ±0.02 nm
Entire wavelength range ±0.1 nm ±0.01 nm
Wavelength linearity
1, 2, 5
±0.01 nm (1520 to 1580 nm)
±0.02 nm (1450 to 1520 nm, 1580 to 1620 nm)
Wavelength repeatability
1, 2
±0.005 nm (1 minute)
Wavelength resolution setting
1, 2
0.02, 0.05, 0.1, 0.2, 0.5, 1.0, 2.0 nm
Resolution bandwidth accuracy
1, 2, 5
±5% (1450 to 1620 nm, resolution setting: 0.1 to 2.0 nm, at the calibration wavelength during
user-defined resolution calibration using an external DFB-LD)
Minimum sampling resolution
1
0.001 nm
Measurement data point 101 to 50001, AUTO
(Wavelength sampling points)
Level sensitivity setting NORM_HOLD, NORM_AUTO, NORMAL, MID, HIGH1, HIGH2 and HIGH3
High dynamic range mode SWITCH (Sensitivity: MID, HIGH1, HIGH2, HIGH3)
Level sensitivity
2, 3, 4, 7
-90 dBm (1300 to 1620 nm, resolution: 0.05 nm or more, measuring sensitivity: HIGH3)
-85 dBm (1000 to 1300 nm, resolution: 0.05 nm or more, measurement sensitivity: HIGH3)
-60 dBm (600 to 1000 nm, resolution: 0.05 nm or more, measurement sensitivity:HIGH3)
Level accuracy
2, 3, 4, 6
±0.4 dB (1310/1550 nm, input level: -20 dBm, measuring sensitivity: NORMAL, MID, HIGH1,
HIGH2, HIGH3)
Leval linearity
2, 3
±0.05 dB (input level: -50 to +10 dBm, measuring sensitivity: HIGH1, HIGH2, HIGH3)
Level flatness
2, 3, 6
±0.1 dB (1520 to 1580 nm)
±0.2 dB (1450 to 1520 nm, 1580 to 1620 nm)
Maximum input power
2, 3
+20 dBm (per channel, full span)
Safe max. input power
2, 3
+25 dBm (total light input power)
Stray light suppression ratio
7, 10
Standard (AQ6370D-12, -10) High performance (AQ6370D-22, -20)
73dB 76dB(typ. 80dB)
Close-in dynamic range
1, 2, 8
Standard (AQ6370D-12, -10) High performance (AQ6370D-22, -20)
±0.1 nm of peak wavelength 37 dB (resolution: 0.02 nm) 45 dB(typ. 50 dB)(resolution: 0.02 nm)
±0.2 nm of peak wavelength 55 dB (resolution: 0.02 nm) 58 dB(typ. 60 dB)(resolution: 0.02 nm)
±0.2 nm of peak wavelength 45 dB (resolution: 0.05 nm) 50 dB(typ. 55 dB)(resolution: 0.05 nm)
±0.4 nm of peak wavelength 62 dB (resolution: 0.05 nm) 64 dB(typ. 70 dB)(resolution: 0.05 nm)
±1.0 nm of peak wavelength 73 dB (resolution: 0.05 nm) 73 dB(typ. 78 dB)(resolution: 0.05 nm)
±0.2 nm of peak wavelength 40 dB (resolution: 0.1 nm) 45 dB(typ. 50 dB)(resolution: 0.1 nm)
±0.4 nm of peak wavelength 57 dB (resolution: 0.1 nm) 60 dB(typ. 67 dB)(resolution: 0.1 nm)
Polarization dependency
2, 3, 6
±0.05 dB (1550/1600 nm)
±0.08 dB (1310 nm)
Sweep time
1, 7, 9
0.2 s (NORM_AUTO)
1 s (NORMAL)
2 s (MID)
5 s (HIGH1), 20 s (HIGH2), 75 s (HIGH3)
Optical return loss
11
Typ. 35 dB (with angled-PC connector)
Optical connectors For optional I/O, AQ9447(*) connector adapter (option) required.
For wavelength reference light source output, AQ9441(*) universal adapter (optional, when
the built-in light source specification is -L1) required.
(*): Connector types: FC, SC
Built-in calibration light source For alignment and wavelength calibration (when the built-in light source specification is -L1)
