2.6 Name Plate
Example for name plates of Integral Flowmeter,
Remote Sensor or Remote Transmitter.
Integral Flowmeter
F0207.ai
*1
Remote Sensor
F0208.ai
*1
Remote Transmitter
F0209.ai
*1
- MODEL: Specied model code
- SUFFIX: Sufx codes of the model code
- STYLE: Specied style code
- SIZE: Nominal size of apparatus
- METER FACTOR:
Sensor constant number of apparatus
- SUPPLY: Power supply voltage of apparatus
- OUTPUT: Output signal of apparatus
- FLUID TEMP.: Fluid temperature of apparatus
- FLUID PRESS: Fluid pressure of apparatus
- AMB. TEMP.: Ambient temperature
- NO.: Manufacturing serial number
- No.: FM 17ATEX0031X:
ATEX type examination certicate number
- Protection type and temperature class for gas
Ex db eb ia IIC T6...T3 Gb
Ex db IIC T6 Gb
Ex db eb IIC T6 Gb:
- Protection type and maximum surface
temperature for dust
Ex tb IIIC T75°C...T130°C Db
Ex tb IIIC T75°C...T150°C Db
Ex tb IIIC T75°C Db:
- Um: Maximum r.m.s. a.c. or d.c. voltage
- ENCLOSURE: Enclosure protection code
- WARNING: Warning to apparatus
- : Name of manufacturer
*1: The product-producing country
