<2. Explosion Protection Type>
4
Remote Sensor
• Type of Gas Atmosphere Protection
Group: II
Category: 2G
Type of Protection:
Ex db eb ia IIC T6…T3 Gb
• Type of Dust Atmosphere Protection
Group: II
Category: 2D
Type of Protection:
Ex tb IIIC T75°C...T150°C Db
• Enclosure:
IP66/IP67 in accordance with EN 60529
• Maximum Surface Temperature:
See Table 2.1 and Table 2.2.
• Ambient Temperature:
See Table 2.1 and Table 2.2.
• Process Temperature:
See Table 2.1 and Table 2.2.
• Um: 250 V
Remote Transmitter
• Type of Gas Atmosphere Protection
Group: II
Category: 2G
Type of Protection:
Ex db IIC T6 Gb
(Transmitter Wiring Terminal: M4 screw type)
Ex db IIC T6 Gb or Ex db eb IIC T6 Gb
(Transmitter Wiring Terminal: Clamp type)
• Type of Dust Atmosphere Protection
Group: II
Category: 2D
Type of Protection:
Ex tb IIIC T75°C Db
• Enclosure:
IP66/IP67 in accordance with EN 60529
• Maximum Surface Temperature: T75°C
• Ambient Temperature: –40°C to +60°C
• Power Supply:
100 to 240 Va.c. (50/60 Hz) / 100 to 120 Vd.c.
24 Va.c. (50/60 Hz) / 24 Vd.c.
• Current I/O: 4 to 20 mA, 32 Vd.c. max.
• Digital I/O: 30 Vd.c. max., 200 mA max.
Table 2.1 Temperature Table
Model Size
Process
Connection
Lining
Temperature Table
Integral
Flowmeter
Remote
Sensor
AXG002, AXG005,
AXG010, AXG015
2.5 to 15 mm
(0.1 to 0.5 in.)
Wafer, Flange PFA Lining Table A Table C
AXG025, AXG032,
AXG040, AXG050,
AXG065, AXG080,
AXG100, AXG125
25 to 125 mm
(1 to 5 in.)
Wafer, Flange PFA Lining Table B Table D
AXG150, AXG200,
AXG250, AXG300,
AXG350, AXG400
150 to 400 mm
(6 to 16 in.)
Wafer, Flange PFA Lining Table A Table C
AXG015, AXG025,
AXG032, AXG040,
AXG050, AXG065,
AXG080, AXG100,
AXG125
15 to 125 mm
(0.5 to 5 in.)
Clamp, Union,
Butt Weld Joint
PFA Lining Table E Table F
AXG002, AXG005,
AXG010, AXG015,
AXG025, AXG040,
AXG050, AXG080,
AXG100, AXG150,
AXG200
2.5 to 200 mm
(0.1 to 8 in.)
Wafer Ceramics Tube Table G Table H
AXW025, AXW032,
AXW040, AXW050,
AXW065, AXW080,
AXW100, AXW125
25 to 125 mm
(1 to 5 in.)
Flange PTFE Lining Table I Table I
AXW150, AXW200,
AXW250, AXW300,
AXW350, AXW400
150 to 400 mm
(6 to 16 in.)
Flange PTFE Lining Table J Table J
