YOKOGAWA Daqstation DX2000 User Manual

7-3
IM 04L42B01-01E
Customizing Actions Using the Event Action and Remote Control Functions (/R1 and /PM1 Options)
1
2
3
4
5
6
7
8
9
10
11
12
13
App
Index
• Event-Action>Action
The action to be executed when an event occurs.
Settings Description
Memory -
Start -
Stop -
Trigger* Can be specified when the DX is configured to record event data.
AlarmACK Cannot be specified when the event is set to Relay, Switch, or Alarm.
Math Can be specified on /M1 and /PM1 options.
MathStart Can be specified on /M1 and /PM1 options.
MathStop Can be specified on /M1 and /PM1 options.
Math rst Can be specified on /M1 and /PM1 options.
SaveDisp Can be specified when the DX is configured to record display data.
SaveEvent Can be specified when the DX is configured to record event data.
Message Set the message number to write the message and the destination. Set the
message destination to all groups (All) or a group number.
Snapshot -
Rate1/2 Can be specified when the function for switching between the trend interval
and the secondary trend interval is enabled.
M.sample -
TimerRst Cannot be specified when the event is set to Timer.
Group Specify the number of the group to be displayed.
Flag Can be specified on /M1 and /PM1 options.
Timeadj Can be specified only when the event is set to Remote.
PnlLoad* Can be specified only when the event is set to Remote.
Comment Specify the comment text block number to display. This function is available for
release numbers 3 and later.
Favorite Choose which registered display to switch to. This function is available for
release numbers 3 and later.
Setting Description
Key Performs the same operation as
pressing the favorite key.
Select>Favorite Screen No Displays the specified favorite screen.
* If you configure the settings so that the Favorite action and the Group
action occur at the same time, only the action whose event action number
is largest will be executed.
AlarmRst This action can only be specified when using the double lock-in sequence of
the alarm annunciator function (see section 3.12), and the event is Remote,
UserKey, or Edge. This function is available for release numbers 3 and later.
* This action is not available on DXs with the /AS1 advanced security option.
7.1SettingtheEventActionFunction
(Includingtheremotecontrolfunctionofthe/R1and/PM1optionsandtheUSERkey)
