YOKOGAWA Daqstation DX2000 User Manual

13-16
IM 04L42B01-01E
USBInterface(/USB1)
Item Specifications
USB port Complies with Rev. 1.1 and host function
Number of ports 2 (one each on the front panel and rear panel)
Power supply 5 V ± 10% , 500 mA (per port)
Devices which need more than 500 mA total bus power for 2 ports can not be connected at the
same time.
Connectable devices Only connect the devices listed below to prevent damage to the devices.
Keyboard Complies with HID Class Ver. 1.1
1104 keyboard/89 keyboard (US) and 109 keyboard/89 keyboard (Japanese)
Number connectable units: 1
External medium USB flash memory
Does not guarantee the operation of all USB flash memories.
External medium such as a hard disk, ZIP, MO, and optical discs are not supported.
Number connectable units: 1
Barcode reader (release number 3 or later)
USB HID Class Ver. 1.1 compatible
English (U.S.) standard USB keyboard compatible
PulseInput(/PM1)
Item Specifications
Pulse input
Number of inputs 3 (8 when using the remote control input terminals)
Input type Isolated from the main circuitry through a photocoupler and built-in isolated power supply for the
input terminals.
Shared common for pulse inputs.
Input type and signal level Voltage-free contact Contactclosedat200Ωorlessandcontactopenat100kΩorgreater
Open collector ON voltage: 0.5 V or less (sink current 30 mA or more), leakage current when
OFF: 0.25 mA or less
Counting Counts the rising edges of pulses.
For voltage-free contact input: Contact open to contact close
For open collector: Voltage level of the terminal H from high to low
Allowable input voltage 30 VDC
Max. sampling pulse period 100 Hz
Minimum detected pulse width
5 ms or more for both low (closed) and high (open)
Pulse detection period Approx. 3.9 ms (256 Hz)
Pulse measuring accuracy ±1 pulse
Pulse count interval Scan interval or 1 s
Miscellaneous Pulse input terminals can be used as remote control input terminals, isolated from remote control
input terminals
Remote control Number of inputs: 5. Same as remote control (/R1) for the other specifications
Computation function Same as the computation function (/M1)
CalibrationCorrection(/CC1)
Item Specifications
Calibration correction method Corrects the measured value of each channel using segment linearizer approximation.
Number of segment points: 2 to 16 (including the start and end points)
Calibration management A function to make sure that calibration is performed regularly (release numbers 4 and later).
ExternalInputFunction(/MC1)
Item Specifications
Function Loads data from other instruments using the Modbus client or Modbus master function and
displays, records, and saves the data.
Number of channels 240 channels (201 to 440)
Display Same as the measurement channels
Data saving Same as the measurement channels
Manual sample Specify up to 120 channels from measurement, computation, and external input channels.
13.5Options
