Specifications
13
DC/AC24VPowerSupply(/P1)
Item Specifications
Rated supply voltage 24 VDC and 24 VAC (50/60Hz)
Allowable power supply voltage range
21.6V to 26.4 VDC/AC
Insulation resistance Betweenpowerterminalandearth:20MΩorgreaterat500VDC.
Withstand voltage Between power terminal and earth: 500 VAC at 50/60 Hz for one minute
Rated power supply frequency (for AC)
50/60 Hz
Allowable power supply frequency range (for AC)
50 Hz±2%, 60 Hz±2%
Power supply fluctuation (for AC)
With variation within 21.6 to 26.4 VDC/AC: ±1digit or less
With variation of ±2 Hz from rated power supply frequency (at 24 VAC): ±(0.1% of rdg+1digit) or
less
Rated power consumption 45 VA (for DC), 70 VA (for AC)
Power consumption Supplyvoltage LCDbacklightoff Normal Maximum
24 VDC 12 VA 20 VA 45 VA
24 VAC (50/60Hz) 20 VA 34 VA 70 VA
MultiBatchFunction(/BT2;releasenumber3orlater)
Item Specifications
Function Individual recording start/stop and file generation operations can be performed for each batch.
Equippable models: DX2010, DX2020, DX2030, DX2040, and DX2048
Number of batches 2 to 12
Batch single operations Recording start/stop, computation reset, message write
Batch overview operations Computation start/stop, report start/stop, manual sampling, setup data save/load
Scan interval Maximum speed of 1 s in normal mode only (same for all batches)
Data type Display or event data only. Trigger mode cannot be used for event data.
Data recording interval Same for all batches
Data files Can be displayed or made into an event data file separately for each batch
Number of display groups Up to twelve per batch
The maximum number of channels per group is ten.
Channels in a display group are sampled for display or event data.
Timers and match time timers 12 max.
Batch single settings Group, trip line, file header, data file name, text field, batch number, and lot number
PROFIBUS-DP(/CP1option;releasenumber3orlater)
Item Specifications
Function A PROFIBUS-DP master device can access internal data in the following ways:
Load measurement channel data
Load computation channel data
Write to communication input data (for up to 32 channels)
Data mapping
Buffer Description Maximum Size
Input Measurement channels are arranged at the start of the buffer. As
many computation channels as can be placed into the buffer are
inserted after the measurement channels.
128 bytes
Output Up to 32 communication input data values is arranged. 128 bytes
Node address 0 to 125
Interface PROFIBUS-DP-V0 Slave
Transmission medium Two dedicated cables (one for each signal line)
Transmission speed/distance 9.6 kbps/1200 m to 12 Mbps/100 m
Terminator No internal terminator (must be terminated externally)
