YOKOGAWA DPharp EJA110E User Manual

<5. Wiring>
49
IM 01C25A01-01E
(2) Flameproof Type
Flameproof packing
adapter
Flexible metal conduit
Wiring metal
conduit
Tee
Drain plug
Apply a non-hardening
sealant to the threads for
waterproofing.
F0512.ai
Figure 5.16 Typical Cable Wiring Using Flameproof
Packing Adapter
connection port for a sealed construction.
F0513.ai
Non-hazardous area
Hazardous area
Flameproof
heavy-gauge
steel conduit
Tee
Drain plug
Seal fitting
Gas sealing device
Flameproof flexible
metal conduit
Apply a non-hardening
sealant to the threads of
these fittings for
waterproofing
After wiring, impregnate the fitting
with a compound to seal tubing.
Figure 5.17 Typical Wiring Using Flameproof Metal
Conduit
5.4 RTD Cable Connection
(EJX910A/EJX930A)
is used.
5.4.1 Connecting Shielded Cable with
Cable Gland (External temperature
input code: -1, -2, -3, and -4)
Transmitter
Cable gland
Electrical connection
RTD cable
with connector
Detail of connector
F0514.ai
Protection Cap Connecting Port
F0515.ai
connection.
F
0
5
1
6
.
a
i
1/2NP
T
T
ype
M20 Type
Gasket
Entry with Seal
Running
Coupler
Backnut
Entry with Seal
Running
Coupler
Backnut
CAUTION
