YOKOGAWA DY100 User Manual

9-4
IM 01F06A00-01E
9. GENERAL DESCRIPTION
200
100
50
0
-50
-29
100
50
0
300
Process Temperature (˚C)
With Indicator
Ambient Temperature (˚C)
85
-50
250
85
-29
80
80
DYF090201.EPS
55
Figure 9.2.1 Ambient Temperature limit (Integral Type)
R=
E - 10.5
0.0236
250
600
10.5 16.4 24.7 42
Power Supply Voltage E(V)
(Ω)
Communication
applicable range
BRAIN and HART
30
Load Resistance
F090202.EPS
Figure 9.2.2 Relationship Between Power Supply
and Load Resistance
HIGH level
LOW level
0 V
0 to 2 V
F090203.EPS
Figure 9.2.3 High and low level (Pulse output)
