YOKOGAWA EXAxt 450 User Manual

Revision Record
ManualTitle: ModelISC450G[Style:S2]InductiveConductivityConverter
Manual Number : IM 12D06D05-01E
Edition Date Remark (s)
1st Jul. 2007 Newly published
2nd Sep.2007 Revisions:
Back-sideofcover,noteadded;p1,FMapprovaldescriptionof
Figure1-1changed;p7,someCAUTIONofFigure3-4andthe
touchscreenadded;p16,sec.4-3-12Serialnumberchanged;
p19, parameter values corrected; p21, parameter values
corrected; p22, note added; p29, made some revisions; p37, some
CAUTIONofthetouchscreenadded;p39top42Sec.9QUALITY
INSPECTIONinserted;p43Sec.10SPAREPARTSsectionand
pagemoved;p44top54APPENDICESpagemoved(p50,noteof
serialnumberadded;p54,APPENDIX6,ControldrawingforFM
approvaladded);CMPL12D06D05-02E,1stEdition,madesome
revisions.
3rd Aug. 2008 Revisions:
Back-sideofcover,noteillustrationadded;p3,Japaneseadded
todisplaylanguage;p4,optioncodes/U,/PM,/H5,/AFTG,/
ANSI,/AM20addedtoModelandcodes;p5to6,Layoutchanged
(Figure3-1.movedandchanged,becauseexternaldimensions
forawninghood/H5,conduitadapter/AFTG,/ANSI,/AM20
added);p7,Figure3-4titlemodified;p8,conduitadapterwork
addedtosubsection3-2-2;p9to14,Layoutchanged(descriptions
afterconduitadapterworkmoved.);p17,Subsection4-3-12.
Serialnumber-->HARTID.changed;p20to35Layoutchanged
(illustration of submenu screen placed on appropriate page);
p37,errorcorrected;p41,someerrorcorrected;p45,someerror
corrected;p49,someerrorcorrected;p50,someerrorcorrected;
p54,NoteofHARTprotocolDDfilesURLadded;Customer
MaintenancePartsListCMPL12D06D05-02Erevisedto2nd
edition,becausePartNo.foroptioncodes/U,/PM,/H5,/AFTG,/
ANSI,/AM20added.
4th Mar.2012 Revisions:
PREFACE,Additionof"Howtodisposethebatteries";p4,Some
revisionofN)SafetyandEMCconformingstandards
(description for EMC revised); p9, Caution mark position on
Section3-3-1changed;.p16,HARTcommunicationmarkadded
toFigure4-1;.p38to39,Section6-2to6-8addedforcalibration
procedure;.p40to41,Section7-4“Contrastadjustment”changed
to“LCDadjustment”,somecautionadded;CustomerMaintenance
PartsListCMPL12D06D05-02E,revisedto4thEdition,someof
illustration changed.

YOKOGAWA EXAxt 450 Specifications

General

Brand	YOKOGAWA
Model	EXAxt 450
Category	Media Converter
Language	English
