2.3.8 Wiring of HAMILTON sensors
Sensor Measurement
FLXA202/FLXA21 Terminals Short *2
FLXA202
/FLXA21
Terminals
Remark
11 12 13 14 15 16 17 18 18/13 19/15
Sensor cable marking (or color) Jumper *1
CHEMTRODE pH Blue Red (White) Yes No 13/14
WU20D
Cable
CHEMTRODE-
ORP
ORP Yes Yes 13/14
CHEMTRODE-
VP
pH E F B A Yes No 13/14 VP6-SC
CLARITRODE pH Blue Red (White) Yes No 13/14
WU20D
Cable
CLARITRODE-
VP
pH E F B A Yes No VP6-SC
CONDCUELL SC
White/
Grey
Blue Green Pink Brown Yellow
Fixed
Cable
CONDCUELL-
VP
SC Blue Yellow Black
Black
Shield
Grey
Grey
Shield
Hamilton
VP Cable
EASYFERM pH Blue Red (White) Yes No 13/14
WU20D
Cable
EASYFERM-
VP
pH E F B A Yes No 13/14 VP6-SC
INCHTRODE pH E F B D A Yes No VP6-SC
MECOTRODE pH Blue Red (White) Yes No 13/14
WU20D
Cable
MECOTRODE-
VP
pH E F B A Yes No VP8-DC
OXYFERM-
VP/OXYGOLD
DO White Green
Green/
Yellow
Black Red
Hamilton
VP Cable
OXYSENS DO Yellow Blue Black Clear Brown
Fixed
Cable
pHEASY pH E F B D A B Yes No
POLILYTE pH Blue Red (White) Yes No
WU20D
Cable
POLILYTE-VP pH White Green Red Blue
Black/
Clear
Yes No
Hamilton
VP Cable
POLILYTE
PLUS-VP
pH White Green Red Blue
Black/
Clear
Yes No
Hamilton
VP Cable
*1: The jumper cables to short are attached to the product.
*2: Jumper cables to short are supplied by users.
Color coding of Variopin cables
PIN A B C D E F G H
Hamilton VP6-SC
Black/
Clear
Red Grey Blue White Green
Hamilton VP8-DC
Black/
Clear
Black
Shield
Red/
Clear
Red
Shield
White Green Yellow Brown
WU20-V-S VP6-SC Clear Brown Black Yellow Red Blue
WU20-V-D VP8-DC
Brown
Core
Brown
Shield
White
Cored
White
Shield
Red Blue Yellow
