YOKOGAWA SMARTDAC+ GP10 - Page 31

23
IM 04L51B01-18EN
Explicit Message
Datatobeaccessed Tagname Supplementary
Information
Datatype
INT32
Datatype
STRING
Batch text field title
(text field title)
dint[12952] string[12952] UTF-8 characters (2
characters)
Up to 20 characters [attach
the terminator ‘\0’ at the
end]
When reading, the
batch text field title
corresponding to the
previous batch group
number and batch text field
number
NULL character if there is
no corresponding batch
group number or batch text
field number
Batch text field string
The content is reflected when the text field number or text field is updated.
Datatobeaccessed Tagname Supplementary
Information
Datatype
INT32
Datatype
STRING
Batch text field string
(batch group number)
dint[13000] ‒ 1 or greater: Batch group
number
When reading, the
batch group number
that performed writing
previously
Default value: 0
Batch text field string
(text field number)
dint[13001] ‒ Text field number
When reading, the
batch text field number
that performed writing
previously
Default value: 0
Batch text field string
(text field)
dint[13002] string[13002] UTF-8 characters (2
characters)
Up to 30 characters [attach
the terminator ‘\0’ at the
end]
When reading, the
batch field characters
corresponding to the
previous batch group
number and batch text field
number
NULL character if there is
no corresponding batch
group number or batch text
field number
• Alarmsetting
The content is reflected according to the settings in use when a value is written in the alarm
value or alarm delay field.
Datatobeaccessed Tagname SupplementaryInformation
Datatype
INT32
Alarm setting
(channel type)
dint[13050] 1: I/O channel
2: Math channel
3: Communication channel
Alarm setting
(channel number)
dint[13051] I/O channel: 1 to 6932
Math channel: 1 to 200
Communication channel: 1
to 500
Continued on next page
