24
IM 04L51B01-18EN
Explicit Message
Datatobeaccessed Tagname SupplementaryInformation
Datatype
INT32
Alarm setting
(alarm level)
dint[13052] 1 to 4: Alarm level
Alarm type dint[13053] 0: OFF
1: High limit alarm
2: Low limit alarm
3: High limit on rate-of-
change alarm
4: Low limit on rate-of-
change alarm
5: Delay high limit alarm
6: Delay low limit alarm
7: Deviation high limit alarm
8: Deviation low limit alarm
Alarm setpoint dint[13054] Alarm setpoint
Alarm delay setting
(channel type)
dint[13060] 1: I/O channel
2: Math channel
3: Communication channel
Alarm delay setting
(channel number)
dint[13061] I/O channel: 1 to 6932
Math channel: 1 to 200
Communication channel: 1
to 500
Alarm delay dint[13062] Alarm delay seconds
DataType
For a PLC, you can specify the type of read or write data using a file number or tag name
in a command. However, the data type is fixed to INT16 for commands “PLC2 Unprotected
Read/Write” and “PLC5 Word Range Read/Write.”
