YOKOGAWA SMARTDAC+ GP10 - Page 37

29
IM 04L51B01-18EN
I/O Messages
•FLOAT
Type Number Operationtype Instance ID Size Datatype
Input/Output channel
(GX/GP main unit)
(GM main unit)
0001 to 0050,
0101 to 0150
Producer 148 400 (4 x 100) FLOAT
0201 to 0250,
0301 to 0350
Producer 149 400 (4 x 100) FLOAT
0401 to 0450,
0501 to 0550
Producer 150 400 (4 x 100) FLOAT
0601 to 0650,
0701 to 0750
Producer 151 400 (4 x 100) FLOAT
0801 to 0850,
0901 to 0950
Producer 152 400 (4 x 100) FLOAT
(GX/GP expandable I/O 1)
(GM sub unit 1)
1001 to 1050,
1101 to 1150
Producer 153 400 (4 x 100) FLOAT
1201 to 1250,
1301 to 1350
Producer 154 400 (4 x 100) FLOAT
1401 to 1450,
1501 to 1550
Producer 155 400 (4 x 100) FLOAT
(GX/GP expandable I/O 2)
(GM sub unit 2)
2001 to 2050,
2101 to 2150
Producer 158 400 (4 x 100) FLOAT
2201 to 2250,
2301 to 2350
Producer 159 400 (4 x 100) FLOAT
2401 to 2450,
2501 to 2550
Producer 160 400 (4 x 100) FLOAT
(GX/GP expandable I/O 3)
(GM sub unit 3)
3001 to 3050,
3101 to 3150
Producer 163 400 (4 x 100) FLOAT
3201 to 3250,
3301 to 3350
Producer 164 400 (4 x 100) FLOAT
3401 to 3450,
3501 to 3550
Producer 165 400 (4 x 100) FLOAT
(GX/GP expandable I/O 4)
(GM sub unit 4)
4001 to 4050,
4101 to 4150
Producer 168 400 (4 x 100) FLOAT
4201 to 4250,
4301 to 4350
Producer 169 400 (4 x 100) FLOAT
4401 to 4450,
4501 to 4550
Producer 170 400 (4 x 100) FLOAT
(GX/GP expandable I/O 5)
(GM sub unit 5)
5001 to 5050,
5101 to 5150
Producer 173 400 (4 x 100) FLOAT
5201 to 5250,
5301 to 5350
Producer 174 400 (4 x 100) FLOAT
5401 to 5450,
5501 to 5550
Producer 175 400 (4 x 100) FLOAT
(GX/GP expandable I/O 6)
(GM sub unit 6)
6001 to 6050,
6101 to 6150
Producer 178 400 (4 x 100) FLOAT
6201 to 6250,
6301 to 6350
Producer 179 400 (4 x 100) FLOAT
6401 to 6450,
6501 to 6550
Producer 180 400 (4 x 100) FLOAT
Input/Output channel
(Continuous channel data
area)*
0001 to 0010,
0101 to 0110,
0201 to 0210,
0301 to 0310,
0401 to 0410,
0501 to 0510,
0601 to 0610,
0701 to 0710,
0801 to 0810,
0901 to 0910
Producer 183 400 (4 x 100) FLOAT
Computation channel A001 to A100 Producer 184 400 (4 x 100) FLOAT
A101 to A200 194 400 (4 x 100)
Continued on next page
