YOKOGAWA UT150 Technical Information

<Toc> <Ind>
2-3
TI 05C01E02-01E 1st Edition : Oct. 31, 2001-00
● UT152 / UT155 Standard Type: Model and Suffix Codes
Model
Model and Suffix Codes
Suffix codes Description
UT155
UT152
Temperature controller ( 96 x 96 x 100mm )
Control
output
-R
-V
-A
Relay output (time-proportional PID or on/off control)
Voltage pulse output (time-proportional PID control)
4 to 20mA output ( current PID) (Note1)
Fixed
N Fixed
Option
/AL
/HBA
/EX
/RET
/RS
/V24
Alarm outputs (2 points) (Note2)
Heater disconnection alarm (includes the function of "/AL" option) (Notes 2 and 3)
SP1/SP2 switching, starting of timer, and RUN/STOP switching by external contacts (Notes 4 and 5)
PV retransmission output in 4 to 20mA (Note 3)
Communication function (Notes 4 and 5)
Power Supply 24V DC / 24VAC
Note 1: The " /HBA" option cannot be specified when selecting "4 to 20mA output" as a control output type.
Note 2: The "/AL" and "/HBA" options cannot be specified at the same time. The "/HBA" option includes the function
of "/AL" option.
Note 3: Two points of external contact inputs are available. Select 2 functions among SP1/SP2 switching, starting of
timer, and RUN/STOP switching.
Note 4: When specifying the "/RS" option, be sure to order the required number of copies of the Communication
Functions User’s Manual (IM 05C01E12-10E) separately. (See Page 2-8)
Temperature controller ( 48 x 96 x 100mm )
• Check the package contents against the list below.
• Temperature controller (of ordered model)
......
1
• Mounting bracket
...............................
1
• User’s Manual (IM 05C01E12-01E)
.............
1
■ Heating/Cooling Type
● UT130 Heating/Cooling Type: Model and Suffix Codes
Model
Model and Suffix Codes
Suffix codes Description
UT130 Temperature controller (48 x 48 x 100mm)
Control
output
for heating
-R
-V
Relay output (time-proportional PID or on/off control)
Voltage pulse output (time-proportional PID control)
Control
output
for cooling
R
V
Relay output (time-proportional PID or on/off control)
Voltage pulse output (time-proportional PID control)
Option
/AL
/HBA
/RS
/V24
Alarm outputs (2 points) (Note1)
Heater disconnection alarm (includes the function of "/AL" option) (Notes 1 and 2)
Communication function (Notes 2 and 3)
Power Supply 24V DC / 24V AC
Note 1: The "/AL" and "/HBA" options cannot be specified at the same time. The "/HBA" option includes the function
of "/AL" option.
Note 2: For heating/cooling type, the "/HBA" and "/RS" options cannot be specified at the same time.
Note 3: When specifying the "/RS" option, be sure to order the required number of copies of the Communication
Functions User’s Manual (IM05C01E12-10E) separately. (See Page 2-8)
Check the package contents against the list below.
• Temperature controller (of ordered model)
......
1
• Mounting bracket
...............................
1
• User’s Manual (IM 05C01E02-01E)
.............
1
