YOKOGAWA UT150 Technical Information

2-4
<Toc> <Ind>
TI 05C01E02-01E 1st Edition : Oct. 31, 2001-00
● UT150 Heating/Cooling Type: Model and Suffix Codes
Model
Model and Suffix Codes
Suffix codes Description
UT150
Temperature controller (48 x 48 x 100mm)
Control
output
for heating
Relay output (time-proportional PID or on/off control)
Voltage pulse output (time-proportional PID control)
4 to 20mA output ( current PID) (Note1)
Control
output
for cooling
R
V
A
Relay output (time-proportional PID or on/off control)
Voltage pulse output (time-proportional PID control)
4 to 20mA output ( current PID) (Note1)
Option
/AL
/HBA
/EX
/RS
/V24
Alarm outputs (2 points) (Note2)
Heater disconnection alarm (includes the function of " /AL" option) (Notes 2 and 3)
SP1/SP2 switching, starting of timer, and RUN/STOP switching byexternal contacts (Notes 3 and 4)
PV retransmission output in 4 to 20mA
Power Supply 24V DC / 24VAC
Note 1: The " /HBA" option cannot be specified when selecting "4 to 20mA output" as a control output type.
Note 2: The "/AL" and "/HBA" options cannot be specified at the same time. The "/HBA" option includes the function
of "/AL" option.
Note 3: The "/HBA", "/EX" and "/RS" options cannot be specified at the same time.
Note 4: Two points of external contact inputs are available. Select 2 functions among SP1/SP2 switching, starting of
timer, and RUN/STOP switching.
Note 5: When specifying the "/RS" option, be sure to order the required number of copies of the Communication
Functions User’s Manual (IM05C01E12-10E) separately. (See Page2-8)
UT150 Heating/cooling Type Table of Option Combination
/AL
/HBA
/EX
/RS
/V24
N/A
A
A
A
AAA
AAA
A
A
A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
/AL
/HBA
/EX
/RS
/V24
-R
-V
-A
Check the package contents against the list below.
• Temperature controller (of ordered model)
......
1
• Mounting bracket
...............................
1
• User’s Manual (IM 05C01E12-01E)
.............
1
A : Available
N/A : Not available
● UT152 / UT155 Heating/Cooling Type: Model and Suffix Codes
Model
Model and Suffix Codes
Suffix codes Description
UT155
Temperature controller ( 96 x 96 x 100mm )
UT152
Temperature controller ( 48 x 96 x 100mm )
Control
output
for heating
Relay output (time-proportional PID or on/off control)
Voltage pulse output (time-proportional PID control)
4 to 20mA output ( current PID) (Note1)
Control
output
for cooling
R
V
A
Relay output (time-proportional PID or on/off control)
Voltage pulse output (time-proportional PID control)
4 to 20mA output ( current PID) (Note1)
Option
/AL
/HBA
/EX
/RS
/V24
Alarm outputs (2 points) (Note2)
Heater disconnection alarm (includes the function of "/AL" option) (Note 2)
SP1/SP2 switching, starting of timer, and RUN/STOP switching by external contacts (Note 3)
Communication function (Note 4)
Power Supply 24V DC / 24V AC
Note 1: The " /HBA" option cannot be specified when selecting "4 to 20mA output" as control output type.
Note 2: The "/AL" and "/HBA" options cannot be specified at the same time. The "/HBA" option includes the function
of "/AL" option.
Note 3: Two points of external contact inputs are available. Select 2 functions among SP1/SP2 switching, starting of
timer, and RUN/STOP switching.
Note 4: When specifying the "/RS" option, be sure to order the required number of copies of the Communication
Functions User’s Manual (IM05C01E12-10E) separately. (See Page 2-8)
-R
-V
-A
Check the package contents against the list below.
• Temperature controller (of ordered model)
......
1
• Mounting bracket
...............................
1
• User’s Manual (IM 05C01E12-01E)
.............
1
