■ Control Output
Control output (OUTPUT1) selects the output type among the current output, voltage pulse
output, and relay contact output signal.
Preset output value is output when the operation is stopped by key operation or contact
input, which takes priority over the manual operation.
Each function can be set by the following parameters.
Setup Parameters
Function Parameter
Control output type selection OT
Control output cycle time CT
I/O
FUNC
Menu
Preset output PO FUNC
Operating Parameters
Function Parameter
Output limiter OL, OH OP.PA
Menu
■ Contact Output
Alarm 1 is output via DO1 (contact output 1).
Alarm 2 is output via DO2 (contact output 2).
Alarm 3 is output via DO3 (contact output 3).
Setup Parameters
Function Parameter
Alarm 1 type AL1
Alarm 2 type AL2
Alarm 3 type AL3
FUNC
FUNC
FUNC
Menu
Operating Parameters
Function Parameter
Alarm 1 setpoint A1
Alarm 2 setpoint A2
Alarm 3 setpoint A3
OP.PA
OP.PA
OP.PA
Menu
