6-8
<Toc> <6. Function Block Diagram and Descriptions>
IM 05D01D02-41E 4th Edition: May 31, 2006-00
■ Retransmission Output
PV, target setpoint, or control output can be output to retransmission output (OUTPUT2/
RET).
Each function can be set by the following parameters.
Setup Parameters
Function Parameter
Retransmission output type RET
Retransmission output scale RTH, RTL
I/O
I/O
Menu
■ 15 V DC Loop Power Supply
The 15 V DC loop power supply (OUTPUT2/RET) uses the same terminal as retransmis-
sion output. The 15 V DC loop power supply can not be used when retransmission output is
used. To use the 15 V DC loop power supply, set “4” in retransmission output type selection
parameter RET.
Each function can be set by the following parameters.
Setup Parameters
Function Parameter
Retransmission output type RET I/O
Menu
