YOKOGAWA WT130 User Manual

IM 253401-01E
App1-3
App
Appendix 1.1 Commands
Communication Commands 1
Syntax EC m <terminator>
“m” indicates element.
m=1 :Element 1
2 :Element 2 (for model 253503 only)
3 :Element 3 (for WT130 only)
4:∑ (for WT130 only)
Query EC? <terminator>
Example EC1
Description ∑ Parameter error 12 will occur if “m” is set to an
illegal value.
E,ST,<interface message GET>
Generates a trigger.
Syntax E <terminator>
ST <terminator>
<interface message GET>
Description • This command is valid only during sample hold
mode.
FL/FL? Determines whether or not filter is used/
inquires about the current setting.
Syntax FL m <terminator>
“m” indicates whether filter is ON or OFF.
m=0 :OFF
1 :ON
Query FL? <terminator>
Example FL1
Description • Parameter error 12 will occur if “m” is set to an
illegal value.
• Filter cannot be switched ON or OFF while
integration is in progress; error 13 will occur.
• While recalling or storing is in progress,
execution error 19 will occur.
HD/HD? Determines whether or not output data
should be updated/inquires about the
current setting.
Syntax HD m <terminator>
“m” indicates the sampling mode.
m=0 :Updates the data at each sampling rate.
1:Hold
Query HD? <terminator>
Example HD0
Description • Parameter error 12 will occur if “m” is set to an
illegal value.
H/H? Determines whether or not to add a head
to measured data output via
communication/inquires about the current
setting.
Syntax H m <terminator>
“m” indicates whether a header is added or not.
m=0 :No header added
1 :Header added
Query H? <terminator>
Example H0
Description • Parameter error 12 will occur if “m” is set to an
illegal value.
HA/HA? Determines whether or not to turn ON the
harmonic analysis function/inquires about
the current setting.
Syntax HA m <terminator>
“m” indicates whether the harmonic analysis
function or normal measurement function is set.
m=0 :Normal measurement
1 :Harmonic analysis
Query HA? <terminator>
Example HA1
Description • Parameter error 12 will occur if “m” is set to an
illegal value.
• When integration is in progress or being
aborted, harmonic analysis cannot be
performed; error 13 will occur.
• Integration cannot be started when the harmonic
analysis function is in progress; error 16 will occur.
• While recalling or storing is in progress,
execution error 19 will occur.
HE/HE? Determines the element of the harmonic
analysis function/inquires about the
current setting.
Syntax HE m <terminator>
“m” indicates the element of the harmonic
analysis function.
m=1 :Element 1
2 :Element 2 (for model 253503 only)
3 :Element 3 (for WT130 only)
Query HE? <terminator>
Example HE1
Description • Parameter error 12 will occur if “m” is set to an
illegal value.
• While recalling or storing is in progress,
execution error 19 will occur.
IC/IC? Sets the integration mode/inquires about
the current setting.
Syntax IC m <terminator>
“m” indicates one of the following integration modes.
m=0 :Normal integration mode
1 :Continuous integration mode
Query IC? <terminator>
Example IC1
Description • Parameter error 12 will occur if “m” is set to an
illegal value.
• Changing the integration mode is not allowed
while integration is in progress; execution error
13 will occur.
• If continuous integration mode is selected, make
sure that the timer preset time is set to a value
larger than “0”.
• If normal integration mode is selected, set the
timer preset time to any desired value.
• While recalling or storing is in progress,
execution error 19 will occur.
IM/IM? Specifies which causes will be allowed to
generate a status byte/inquires about the
current setting.
Syntax IM m <terminator>
“m” is assigned as follows (0 ≤ m ≤ 15).
m=1 :Computation end
2 :Integration end
4 :Syntax error
8 :OVER
Query IM? <terminator>
Example IM15
Description • Parameter error 12 will occur if “m” is set to an
illegal value.
• If more than one of these causes is to be
allowed, set “m” to the sum of their individual
“m” values. For instance, if all causes are to be
allowed, set “m” to 15 (=1+2+4+8).
IP Stops integration.
Syntax IP <terminator>
Description • If an attempt is made to stop integration when
integration has already been interrupted
(stopped), execution error 44 will occur.
• While recalling or storing is in progress,
execution error 19 will occur.
IR Resets integration.
Syntax IR <terminator>
Description • If an attempt is made to reset integration while
integration is in progress, execution error 45
will occur.
• While recalling or storing is in progress,
execution error 19 will occur.
