YOKOGAWA WT1800 User Manual

21-1
IM WT1801-01EN
21 Ethernet Communication (Network)
You can configure TCP/IP parameters and use the optional Ethernet interface to perform the following tasks.
TCP/IP
TCP/IP settings for connecting to an Ethernet network.
Set the IP address, subnet mask, and default gateway.
Click here.
FTP Server (FTP Server)
You can connect the WT1800 as an FTP server to a network.
You can connect to the WT1800 from a PC on the same network and retrieve setup data, numeric data,
waveform display data, and screen image data.
Click here.
Network Drive (Net Drive)
You can save the WT1800’s setup data, numeric data, waveform display data, and screen image data to a
network drive. You can also load the setup data from a network drive into the WT1800.
Click here.
SNTP
The WT1800 clock can be set using SNTP. When the WT1800 is turned on, the date and time are set
automatically.
Click here.
To connect a PC to the WT1800, use a hub or router, and connect to a network. Do not connect a PC directly
to the WT1800.

YOKOGAWA WT1800 Specifications

General

Model	WT1800
Basic Power Accuracy	±0.1% of reading
Frequency Range	DC, 0.1 Hz to 1 MHz
Harmonic Analysis	Yes, up to 500th order
Voltage Range	1.5 V to 1000 V
Current Range	0.5 A to 50 A
Display	8.4-inch LCD
Interfaces	USB, Ethernet, GP-IB
Sampling Rate	2 MS/s
Dimensions	426 mm x 177 mm x 400 mm
