9-12
IM WT1801-01EN
Rated Time of Integrated D/A Output (D/A Output Rated Time;
Option)
This setting appears on models with the 20-channel D/A output option. When integrated values are output
through D/A output, a rating value (the same value as the measurement range) is continuously applied, the
integrated value after the specified amount of time has elapsed is taken to be 100%, and the D/A output at that
point is 5 V. It is assumed that the change in the D/A output from 0% of the integrated value (0 V) to 100% of
the integrated value (5 V) will occur linearly over time, and the D/A output value is determined by the ratio of the
actual input level to this assumed straight line.
For information about the relationship between the measured integrated D/A output value and the voltage, see
“Relationship between Output Items and the D/A Output Voltage.”
Click here.
Setting the Rated Time for Integrated D/A Output
You can set the hour, minute, and second within the following range.
00000:00:00 to 10000:00:00
This setting is valid in the following integration modes.
Manual integration mode
Real-time normal integration mode when the integration timer is set to 00000:00:00
In the following integration modes, the rated time for integrated D/A output is set to the same time that the
timer is set to.
Normal integration mode
Continuous integration mode
Real-time normal integration mode when the integration timer is not set to 00000:00:00
Real-time continuous integration mode
When the rated time for integrated D/A output is set to 00000:00:00, the D/A output for the integrated value is
fixed at 0 V.
9 Integrated Power (Watt hours)
