YOKOGAWA WT1800 User Manual

7-12
IM WT1801-01EN
Saving the Display Configuration (Save Custom Items)
You can save the display configuration that you have created to the specified storage medium. The extension is
.TXT.
•
Displaying a File List and Specifying the Save Destination
(File List)
On the file list, specify the save destination. For information about how to configure the file list display and
how to operate files and folders, see “File Operations (Utility).”
Click here.
• Automatic File Naming (Auto Naming)
This is the same as the auto naming feature for saving and loading data.
Click here.
• File Name (File Name)
This is the same as file name setting for saving and loading data.
Click here.
• Saving (Save Exec)
Saves the display configuration.
• Note that if there is a file with the same name in the save destination, it will be overwritten without warning.
• File names are not case sensitive.
Turning the Display Frame On and Off (Display Frame)
This is the same as turning the display frame on and off in the 4-, 8-, and 16-value displays.
Click here.
7 Numeric Data Display

YOKOGAWA WT1800 Specifications

General

Model	WT1800
Basic Power Accuracy	±0.1% of reading
Frequency Range	DC, 0.1 Hz to 1 MHz
Harmonic Analysis	Yes, up to 500th order
Voltage Range	1.5 V to 1000 V
Current Range	0.5 A to 50 A
Display	8.4-inch LCD
Interfaces	USB, Ethernet, GP-IB
Sampling Rate	2 MS/s
Dimensions	426 mm x 177 mm x 400 mm
