Tech Note: Unreleased Date: October 22, 2013
Appendix A
Number
MS Code
Description
1
1
K9471UA Oil and gas dust filter. Only screws on the tip of the probe.
1
2
E7042UQ YCA version of oil and gas dust filter. Screws and bolts on to
the probe.
2 M1234DK
Hastelloy O
2
cell bolt.
3 M1200DF
Washer for M1234DK.
4 E7042BR Contact plate.
5 K9470BM Calibration tube (J-Tube)
6 E7042BB Zirconia cell.
7 K9470BJ Metal o-ring.
8 K9470BA Heater assembly nut.
9 E7042BS Contactor spring.
10 Y9640NU Bolt to join the terminal box to the air connector assembly
and probe.
11 Y9600SU Washer for Y9640NU.
12 K9470BE Terminal box bolt cover.
13 K9470AN Air connector assembly.
14 B1011ER Air connector assembly o-ring.
15 Y9408LU Screw to hold K9470BE to K9470AN.
16 K9470BS Terminal box. (Cap is K9477AP)
17 K9470AL Plate to hold down caps in K9470AN.
18 Y9101XB O-ring to keep Y9430LU from falling off of the plate.
19 Y9430LU Screw to secure plate to the heater strut.
20 K9470AS Air cap.
21 B1014ER O-ring to fit on the air caps.
22 B1013ER O-ring for the air connector holes.
23 ZR22A Heater strut assembly.
24
25 Y9408LU Screw to secure plate to the air connector.
26 K9472YD Upper terminal block.
27 K9472YC Lower terminal block.
28 Y9730YA Spacer for Y9318JU.
29 Y9318JU Terminal block to terminal box screw.
30 K9470BG Pt1000 RTD for measuring cold junction temperature.
31 Y9406JU Terminal block screw.
32 E7042AY Meshed filter.
