RF605C is more
suitable for the
Canon cameras
Names of RF605 Parts
RF605N is more
suitable for the
Nikon cameras
A-Hot shoe stand/Hot shoe contacts: install flash
B-2.5mm shutter release socket
C-Focus light (Green)/shutter indicator light
(Red),in RF-603 TRX status, the AF-assist light
will blink once in every 2 seconds.
D-PC interface(output)
E-Waken indicator (Green)/trigger indicator light
(Red),in RF-602 RX , the trigger indicator
light will blink once in every 2 seconds.
F-Power switch: ON means turn on, while OFF
means turn off
G-Buttons and display (see below page)
H-Multifunction button (see below page)
I-Hot shoe fixed foot and contacts: mounted on
the camera hot shoe
J-Locking ring
K-Battery compartment
L-the battery compartment cover
status
3
