5
Preparation before using
1.Battery Installation:
Slide to open the battery compartment, install two AAA
batteries(not included) for two transceivers according to the
"+/-"direction shown.
The low battery Indicator( )
The low battery indicator will blink when the batteries are low.
Please replace the battery.
2.Fix the transmitter on the hot shoe of the camera:
Mount the transmitter on the hot shoe of the camera through
the hot shoe mounting foot, then tight the locking screw.
Supports installing the flash on the transmitter (on-top
flash， as the picture shown).
3.Fixed the receiver and flash
Mount the receiver on the mini stand of the flash attached or
other fixed device (not included), and tight the locking screw.
Install the flash on the hot shoe of the receiver, lock the flash
and ensure all links are fixed well.
Make sure all the transceivers have been fixed, the flash set to manual “M”
mode.
