Yongnuo YN-622N User Manual

6
2.Installing the Transceiver on the Camera (As
Transmitter)
※ Remove the batteries when the product
is not used for long time.
※ Please replace the both two batteries at
the same time.
Open the cover and install two AA
batteries (excluded)according to
the marks , rechargeable batteries
of 1 .2 V c a n b e u s ed . St at u s
indicator will blinks in red when the
battery is low, replace the battery.
1). Unscrew the locking ring of the transceiver.
2). Slip the mounting foot into the hot shoe of the camera.
3). Turn the locking ring according to the direction
of arrow, the locking pin will protrude from the
mounting foot.
※ It is supported that install a on-top flash (or master
unit) on the transmitter, refer to p15.
Preparation Before Use
1. Installing the Batteries

Yongnuo YN-622N Specifications

General

Brand	Yongnuo
Model	YN-622N
Category	Transceiver
Language	English
