TTL: E-TTL(II) Fully Automatic Flash
The FEC adjustment range is within -3 to +3EV, It’s
supported to press select/set button group to adjust the FEC
value. If the FEC value is set on the flash, i
M: Manual Flash
The adjustment range is within 1/128-1/1, press [LEFT] or
[RIGHT] button to adjust, press the [UP] or [RIGHT] button
for fine adjustment.
SS(Super Sync):refer to P.14.
OFF: This group is not participate in flash.
*Long press the [GR/*] button to quickly turn off the A/B
two groups at the same time.
t will plus with the
FEC value set on the controller.
Settings
1.GR-Grouping flash mode: set different flash
modes for different groups.
1).short press the [GR/*] button to
choose the setting groups.
2).Short press the [ ] button
to set the flash mode of the
selected group, each press of
the setting as below:
To Next Page
